Variations on a stickman graph: Analyzing the Twitter minions

12

One of our customers asked if I could show him how to reproduce a stickman graph that David McCandless (ala, Information is Beautiful) had created - see screen capture below. I'm not sure that it's the best kind of graph for the occasion, but of course SAS can be used to create it! ...

David's graph uses 100 stickmen to represent all the Twitter users, and divides them into 5 categories. Each category is represented by a color. In the SAS dataset, I represent each stickman by an X and Y pair (for the position on the grid), and Color_value (1-5, for the 5 color categories), using the following code:

data my_data;
retain x y;
input color_value @@;
if x=. then y=5;
x+1;
if x=21 then do;
 x=1;
 y=y-1;
 end;
datalines;
1 1 1 1 2 2 2 2 2 2 2 2 2 2 4 4 4 4 4 5
1 1 1 1 2 2 2 2 2 2 2 2 2 2 5 5 5 5 5 5
1 1 1 1 2 2 2 2 2 2 2 2 2 2 5 5 5 5 5 5
1 1 1 1 2 2 2 2 2 2 2 2 2 2 5 5 5 5 5 5
1 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 5
;
run;

I create a user-defined format so that the numeric Color_values (1-5) print in the graph legend as the desired text descriptions, and then plot the points with SAS/Graph Proc Gplot using plot y*x=color_value, and the following symbol statements (the '80'x character of the Webdings font is the stickman figure).

symbol1 font='webdings' value='80'x height=15 color=cxec008c;
symbol2 font='webdings' value='80'x height=15 color=cx8cc63f;
symbol3 font='webdings' value='80'x height=15 color=cx662d91;
symbol4 font='webdings' value='80'x height=15 color=cx00aeef;
symbol5 font='webdings' value='80'x height=15 color=cx939598;

The graph came out like this, which is almost what we want:

twitter_as_100_people

I then used axis statements to suppress the axis tick marks, numeric values, and lines (axis1 label=none style=0 value=none major=none minor=none), and have the following plot which is a much 'cleaner' version:

twitter_as_100_people1At this point, I would have "called it a day" and been done. But McCandless' version was a little more "politically correct" and had both stickmen and stickwomen ... which makes creating the graph a bit more complex. The technique I was using only allows you to have 1 color and marker shape per each category. Therefore I changed techniques, and used gplot to create a blank graph, and then used annotate to programmatically draw the stickpeople (annotate always gives you total control).

data anno_markers; set my_data;
length function color $8;
xsys='2'; ysys='2'; hsys='3'; when='a';
function='label'; style='webdings'; position='+'; size=15;
color='black';
if color_value=1 then color='cxec008c';
if color_value=2 then color='cx8cc63f';
if color_value=3 then color='cx662d91';
if color_value=4 then color='cx00aeef';
if color_value=5 then color='cx939598';
/* make even x-values the female stick-figure, and odd ones the male */
if mod(x,2)=0 then text='80'x;
else text='81'x;
run;

Add to that a few carefully placed (annotated) text labels that explain what the colors mean, and we have a graph very much like McCandless' beautiful version:

twitter_as_100_people2

What are the pros & cons of these stickman graphs, and what other graph might better represent this data?
